NISE-110-A02
Fanless compact low-power industrial PC with Intel Atom x7211E CPU
Features
- Intel Atom x7211E Dual Core CPU
- Up to 16 GB DDR5 RAM
- 1x M.2 2242/2280 NVME, 1x mSATA
- 2x USB 3.2, 2x USB 2.0
- 1x HDMI, 1x DisplayPort
- -40 ~ 60°C operating temperature
- 9-30V DC wide range input
- CE, FCC Class A and UL certified
Powered by the latest generation of Intel Atom® x7211E Dual Core (formerly codenamed “Alder Lake–N ”), NISE110-A02 provides outstanding performance not only on computing but also on graphics, and it presents a brand new opportunity for both intelligent and industrial computing solutions. Up to 16G DDR4 memory, NISE 110 have several options on storage devices like M.2 and miniPCIe. The NISE 110 has high integration ability with 3 x TSN 2.5GbE Lan ports, 4 x COM ports (2x RS232 and 2xRS232/422/485), which makes it a real intelligent system for various applications such as factory automation applications, network applications (wi th optional Wi Fi module and 5G/4G/LTE module) and communication applications (with optional GPIO, RS232/422/485). For more harsh environment, the NISE110 also provide extended operation temperature SKU from -40 up to 70 degree C.
Technical details
| Add-ons: | Full-size Mini PCIe, M.2 2242 B key, SIM Socket |
|---|---|
| CPU: | Intel Atom® x7211E |
| Certificates: | CE, CE approval- EN61000-6-2- EN61000-6-4, FCC Class A, UL |
| DC Input: | 3-pin pluggable terminal block |
| Ethernet: | 2.5G |
| Ethernet Ports: | 1x, 2x, 3x |
| Humidity: | 10% ~ 90% (non-condensing) |
| Memory: | 1x DDR5 Slot |
| Memory capacity: | 4 GB, 8 GB, 16 GB |
| Mounting: | Wall-mount (optional) |
| Operating Temperature: | -20°C ~ 60°C |
| Operating system: | Linux, Windows 10, Windows 10 IoT, Windows 11, Windows 11 IoT |
| Power supply: | 9 ~ 30V DC |
| Serial Ports: | RS-232, RS-422, RS-485 |
| Storage: | M.2 2242 NVMe, M.2 2280 NVME, mSATA SSD |
| TPM: | TPM 2.0 |
| USB: | USB 2.0, USB 3.2 Gen 1 |
| USB Ports: | 1x, 2x, 3x, 4x |
| Video: | DisplayPort, HDMI |
