NISE-109-E01
Fanless compact low-power industrial PC with Intel Atom x6211E CPU
Features
- Intel Atom x6211E Dual Core CPU
- Up to 16GB DDR4 RAM
- 1x M.2 2242 NVME, 1x 2,5" SSD
- 3x USB 3.0, 4x serial Ports
- 2x Intel I210 GbE LAN Ports
- TPM 2.0
- -20 ~ 70 °C operating temperature
- CE/FCC class A certified
Powered by the latest generation of Intel® Atom® x6211E Dual Core (formerly codenamed “Elkhart Lake”), NISE 109 provides outstanding performance not only on computing but also on graphics, and it presents a brand new opportunity for both intelligent and industrial computing solutions. Up to 16G DDR4 memory, NISE 108 have several options on storage devices like M.2 and SSD. The NISE 109 has high integration ability with optional mini-PCIe module , 4 x COM ports (2 x RS232 and 2 x RS232/422/485), which makes it a real intelligent system for various applications such as factory automation applications, network applications (with optional Wi-Fi module and 4G/LTE module) and communication applications (with optional GPIO, RS232/422/485). For more harsh environment, the NISE 109 also provide extended operation temperature SKU from -20°C up to 70°C.
Technical details
| Add-ons: | Full-size Mini PCIe, M.2 2242 B key, SIM Socket |
|---|---|
| Audio: | Microphone input, Speaker out |
| CPU: | Intel® Atom® x6211E |
| Certificates: | CE, EN 61000-6-2, FCC Class A |
| DC Input: | 3-pin pluggable terminal block |
| Ethernet: | Gigabit |
| Ethernet Ports: | 1x, 2x |
| Humidity: | 10% ~ 90% (non-condensing) |
| Memory: | 1x DDR4 Slot |
| Memory capacity: | 2 GB, 4 GB, 8 GB, 16 GB |
| Mounting: | Wall-mount (optional) |
| Operating Temperature: | -20°C ~ 70°C |
| Operating system: | Linux, Windows 10, Windows 10 IoT |
| Power supply: | 9 ~ 30V DC |
| Serial Ports: | RS-232, RS-422, RS-485 |
| Storage: | 2,5" SSD, M.2 2242 NVMe |
| TPM: | TPM 2.0 |
| USB: | USB 2.0, USB 3.0 |
| USB Ports: | 1x, 2x, 3x, 4x |
| Video: | DisplayPort, HDMI |
