NISE-108
Fanless compact low-power industrial PC with Intel Celeron Quad Core CPU
Features
- Intel Celeron J3455 Quad Core CPU
- Up to 8GB DDR3 RAM
- 1x M.2 2242 NVME, 1x 2,5" SSD
- 2x DisplayPort Connector
- 2x USB 2.0, 2x USB 3.0, 4x serial interface
- -10 ~ 60°C operating temperature
- 24V DC input
- CE/FCC certified
Powered by the latest generation of Intel® Celeron® J3455E processor Quad Core, 1.50GHz (formerly codenamed "Apollo Lake"), NISE 108 provides outstanding performance not only on computing but also on graphics, and it presents a brand new opportunity for both intelligent and industrial computing solutions. Up to 8G DDR3L memory, NISE 108 have several options on storage devices like M.2, HDD and SSD. In addition to no cable connection on the storage of NISE 108, it brings NISE 108 the sustainability to work in harsh nvironment both with temperature and vibration concern. The NISE 108 has high integration ability with optional mini-PCIe module and 3 x COM ports, which makes it a real intelligent system for various applications such as factory automation applications, network applications (with optional Wi-Fi module) and communication applications (with optional GPIO, RS232/422/485). NISE 108 is definitely the top choice for M2M intelligent system and factory automation platforms.
Technical details
| Add-ons: | Full-size Mini PCIe, M.2 2242 B key, SIM Socket |
|---|---|
| CPU: | Intel® Celeron® J3455 |
| Certificates: | CE, FCC Class A |
| DC Input: | 3-pin pluggable terminal block |
| Ethernet: | Gigabit |
| Ethernet Ports: | 1x, 2x |
| Humidity: | 10% ~ 90% (non-condensing) |
| Memory: | 1x DDR3 Slot |
| Memory capacity: | 2 GB, 4 GB, 8 GB |
| Mounting: | Wall-mount (optional) |
| Operating Temperature: | -10°C ~ 55°C |
| Operating system: | Linux, Windows 10, Windows 10 IoT |
| Power supply: | 24V DC |
| Serial Ports: | RS-232, RS-422, RS-485 |
| Storage: | 2,5" SSD, M.2 2242 NVMe |
| USB: | USB 2.0, USB 3.0 |
| USB Ports: | 1x, 2x, 3x, 4x |
| Video: | DisplayPort |
